Audison AV 1.1 II Tweeter | 180 W Peak Power Filtered | 1.1 in. | 4 ohm

AV 1.1 II

AV 1.1 II

Tweeter | 180 W Peak Power Filtered | 1.1 in. | 4 ohm

The Audison Voce AV 1.1 II tweeter showcases its engineering prowess by achieving Hi-Res Audio certification, a notable accomplishment for a tweeter with a Tetolon soft dome. Tetolon was specifically chosen for its superb sound timbre, allowing the tweeter to extend its frequency response up to 40kHz. This design provides unparalleled clarity and depth in high-frequency sound reproduction. Equipped with AIF (Any Install Faceplate) technology, the AV 1.1 II offers flexible installation options with various faceplates and accessories, ensuring perfect integration into any vehicle environment. This careful blend of advanced materials and versatile installation underscores the tweeter’s appeal to today’s car audio enthusiasts who demand the best performance.

Technical Specs
Nominal diameter Inch 1.1 in
Nominal diameter 28 mm
Impedance 4 Ohm
Minimum Impedance 3.9 Ohm
Power Handling – Peak 180 W
Hi-Pass filtered @ 1,8 kHz – 12dB Oct.
Power Handling – Continuous 10 W
Sensitivity 91 dB
SPL measured at 2.83V/1m;
Frequency Response 1000 – 40000 Hz Hz
Comply with HiRes Audio JAS, testing condition IEC 60268-5.
Voice Coil Ø Inch 1.1 in
Voice Coil Ø 28 mm
Magnet Material NEODYMIUM
Voice Coil Material CCAW
Dome Material TETOLON FIBRE
Former Material ALUMINIUM
Diaphragm Surround Material TETOLON FIBRE
Ferrofluid No
Electric-acoustic Specs
Re 3.2 Ohm
Fs 900 Hz
Le 0.02 mH
Mms 0.38 g
Cms 0.088 mm/N
BL 2.15 T•m
Qts 1.1
Qes 1,5
Qms 4.4
