Audison AV 3.0 II Mid Range | 100 W Peak Power | 70 mm (3.5 in.) | 4 ohm

AV 3.0 II

AV 3.0 II

Mid Range | 100 W Peak Power | 70 mm (3.5 in.) | 4 ohm

The Audison VOCE II AV 3.0 II mid-range speaker is meticulously crafted to deliver exceptional clarity and rich detail in the crucial mid-frequency range. Featuring a specialized cone made from pressed paper with cotton fibers, the AV 3.0 II offers an ideal balance of rigidity and responsiveness, enhancing sound reproduction for today’s car audio enthusiasts. This mid-range unit integrates seamlessly into any system with its compact design and is equipped with OEM-style connectors, ensuring straightforward and versatile installation options.

Technical Specs
Nominal diameter 70 mm
Minimum Impedance 3.2 Ohm
Power Handling – Peak 100 W
Power Handling – Continuous 50 W
Sensitivity 90 dB
SPL measured at 2.83V/1m;
Frequency Response 160 ÷ 13000 Hz
(-6dB)
Voice Coil Ø 26 mm
Chassis Material ALUMINIUM
Magnet Material NEODYMIUM
Magnet size D x d x h 24.9-6 mm (in.)
Voice Coil Material CCAW
Former Material GLASS FIBER
Cone Material SEMI-PRESSED PAPER
Surround Material RUBBER
Xmax Inch 0.06 in
Xmax 1.4 mm
Xmech Inch 0.13 in
Xmech 3.2 mm
Voice Coil Winding Height Inch 0.21 in
Voice Coil Winding Height 5.3 mm
Gap Height Inch 0.18 in
Gap Height 4.5 mm
Crossover name no
Electric-acoustic Specs
D Inch 5.518 in
Re 2.9 Ohm
Fs 150 Hz
Le 0.1 mH
Vas Ft 0.022 ft
Vas 0.61 l
Mms Oz 0.102 oz
Mms 2.9 g
Cms 0.39 mm/N
BL 3.5 T•m
Qts 0.58
Qes 0.65
Qms 5.45
Flux Density 0.78
General
Weight 0.15 kg
